Designing believable 3D sound with binaural audio

Binaural cues – how we hear left, right and straight ahead

Binaural cues rely on the fact that we have two ears, separated by the head. They are most important for localising sound in the horizontal plane – whether something is to your left, right or in front.

Two main effects are at work:

• Interaural Time Difference (ITD)
  A sound arriving from the right reaches the right ear slightly earlier than the left ear. The brain can detect time differences of only a few microseconds and uses them as a strong cue to direction.
• Interaural Level Difference (ILD)
  The head acts as a partial barrier to sound, especially at higher frequencies. A sound on the right will be slightly quieter at the left ear because it has travelled further and been shadowed by the head. That level difference also points to the sound being on the right.

Headphone and spatial audio systems that respect and reproduce realistic ITDs and ILDs can place sounds reliably around the listener. Systems that ignore them often leave everything sounding as if it is inside the head.

Monoaural cues – height, distance and timbre

Not all localisation depends on having two ears. Monoaural cues work with a single ear and are especially useful for:

• Vertical localisation – whether a sound is above, below or at ear height
• Front and back discrimination
• Perceived distance

As sound approaches the ear, it is filtered by the complex shape of the torso, head and outer ear. Different arrival angles produce different patterns of amplification and attenuation across frequency. The auditory system learns these patterns over a lifetime and uses them as fingerprints for direction and distance.

For distance, the brain also takes into account:

• Overall level of a familiar sound
• The balance between direct sound and reflections
• Stronger attenuation of high frequencies with increasing distance

This is why a personalised approach to spatial audio can make such a difference – your monoaural cues are shaped by your anatomy.

The cone of confusion – when cues disagree

There are regions in space where binaural cues become ambiguous. One of the most important is known as the cone of confusion.

For a given position to the side of the head, there is a roughly conical surface of points that produce almost identical ITDs and ILDs. A sound source located anywhere on that cone can give the same binaural cues, so the brain has to rely more heavily on monoaural information and on changes in cues when you move your head.

For audio product design, this is a reminder that:

• Static cues alone may not be enough for robust localisation in every direction.
• Allowing or tracking natural head movement can resolve ambiguity and improve realism.
• Testing systems with realistic head motion and source positions is essential.

Binaural decolouration – why you do not hear constant timbre changes

Given how strongly your head, ears and torso colour incoming sound, you might expect every change in source position to produce a noticeable change in timbre. In practice, this is not what we perceive.

The auditory system performs a form of binaural decolouration. It is effectively calibrated to your anatomy and learns to treat the colouration from your head and ears as normal. When it has localised a source, it can internally compensate for some of that frequency shaping, helping you hear the underlying sound consistently.

This process is:

• Adaptive – if your anatomy changes, localisation and decolouration may initially suffer, then improve over time.
• Sensitive to speed – rapid head movements or very extended sound sources, like breaking waves, can reveal the underlying colouration in interesting ways.

For engineers, this underlines why generic one size fits all processing can sometimes feel slightly off, and why user adaptation over time can matter.

From theory to practice – how binaural audio is created

Binaural audio techniques aim to reproduce at the ears the same cues that would be present if you were listening in a real space.

There are two main approaches.

1. Recording with realistic ears

Binaural recordings can be made by placing small microphones:

• In a real person’s ear canals
• In the ears of a specially built dummy head

These recordings automatically capture ITDs, ILDs and the detailed timbral changes introduced by the head and torso for that specific geometry. When played back over headphones, the listener often perceives sounds as being located outside the head, in the space where they were recorded.

2. Synthesis with Head Related Transfer Functions

For more flexible applications, audio is often synthesised using Head Related Transfer Functions (HRTFs).

• An HRTF describes how sound from a specific direction is filtered by the head and body before reaching each ear.
• By filtering a mono signal with the appropriate left and right ear HRTFs, you can create a binaural version that appears to come from that direction.
• HRTFs can be measured for an individual or taken from databases built from many people.

With head tracking, the system can update the HRTF in real time as the listener moves, keeping virtual sound sources fixed in space and greatly enhancing immersion in VR or AR environments.

The engineering challenge – individual fit and real world devices

The main limitation of binaural synthesis is that no two listeners have exactly the same anatomy.

If there is a mismatch between the HRTFs used and the listener’s own HRTFs, localisation can become less precise and artefacts may appear. Small differences in ear shape or head size can make surprisingly large differences in perceived realism.

For product teams, that creates several challenges:

• Choosing or designing HRTFs that work reasonably well for most listeners
• Understanding which aspects of HRTF mismatch are most tolerated and which are most critical
• Accounting for headphone and earbud fit, which can modify the effective HRTF again
• Balancing computational cost, latency and perceptual quality in real time systems

This is exactly where targeted measurement, simulation and listening tests can de risk design decisions.
